07 SP/SWG/SGN General Specification of Direct Current Motor
| Type | General Specification | ||||||
| VOLTAGE (vdc) |
AMPS (A) |
SPEED (RPM) |
OUTPUT (W) |
TORQUE (kg-cm |
RATING (min) |
WEIGHT (kg) |
|
| 07 | 12 | 3.5 | 1800 | 30 | 1.62 | CONT | 1.3 |
| 24 | 1.8 | ||||||
| 90 | 0.5 | ||||||
| 12 | 5.2 | 3200 | 50 | 1.83 | 30 min | 1.3 | |
| 24 | 2.6 | ||||||
| 90 | 0.7 | ||||||
